Product Summary
The MAX4624EUT+T is low-on-resistance, lowvoltage single-pole/double-throw (SPDT) analog switches that operate from a single +1.8V to +5.5V supply. It has break-before-make switching.This device also owns fast switching speeds (tON = 50ns max, tOFF = 50ns max). It is applied in power routing,battery-operated equipment,audio and video signal routing,low-voltage data-acquisition systems,communications circuits,pcmcia cards,cellular phones,modems,hard drives,etc.
Parametrics
Absolute maximum ratings:(1)Voltages Referenced to GND: V+, IN:-0.3V to +6V;COM, NC, NO (Note 1):-0.3V to (V+ + 0.3V); (2)Continuous Current NO, NC to COM:卤200mA; (3)Peak Current NO, NC to COM(pulsed at 1ms, 10% duty cycle max):卤400mA; (4)Continuous Power Dissipation,6-Pin SOT23-6 (derate 7.1mW/掳C above +70掳C) :571mW; (5)Operating Temperature Range:MAX462_EUT:-40掳C to +85掳C;Junction Temperature:+150掳C;Storage Temperature Range:-65掳C to +150掳C;Lead Temperature (soldering, 10s):+300掳C.
Features
Features:(1)Low RON:1惟 max (+5V Supply);2惟 max (+3V Supply); (2)0.12惟 max RON Flatness (+5V Supply); (3)Overcurrent Protection; (4)+1.8V to +5.5V Single-Supply Operation; (5)Available in SOT23 Packages; (6)Fast Switching: tON = 50ns max, tOFF = 50ns max; (7)TTL-Logic Compatible (+5V Supply); (8)Pin Compatible with MAX4544; (9)Guaranteed Break-Before-Make (MAX4624); (10)Guaranteed Make-Before-Break (MAX4625).
Diagrams
<IMG src="http://www.seekic.com/uploadfile/ic-mfg/2011310193046344.jpg" border=0>
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MAX4624EUT+T |
Maxim Integrated Products |
Analog Switch ICs 1Ohm Low-V SPDT Analog Switch |
Data Sheet |
|
|
||||||||||||
 |
MAX4624EUT+TG103 |
Maxim Integrated Products |
Analog Switch ICs Low-Voltage Dual SPDT Audio Clickless Switches with Negative Rail Capability |
Data Sheet |
Negotiable |
|
||||||||||||
